Wire Mesh Belt Shot Blasting Machine

Ted has developed a set of wire mesh belt shot blasting machine for surface treatment (roughening, glazing, calendering) of marble tiles, natural marble or block slabs, granite, cement tiles, chain paving, curbs, etc. The workpieces are transported by a horizontal mesh conveyor belt; The size of the conveyor belt of the wire mesh belt shot blaster can be determined according to the size of the workpiece.The blasting effect is obtained by centrifugal projection of spherical steel balls (without compressed air).

Send Inquiry

Product Description

The workpieces are transported by a horizontal mesh conveyor belt; The size of the conveyor belt of the wire mesh belt shot blaster can be determined according to the size of the workpiece.The blasting effect is obtained by centrifugal projection of spherical steel balls (without compressed air).

The workpiece will be placed in the inlet area by manual or automatic system and then introduced into the blast chamber of a series of turbines, After a certain blast time,properly positioned part of the channel, providing blasting of the projected surface of the metal abrasive

Depending on the desired effect or the hardness of the surface to be treated, the speed of transportation or blast wheel can be changed.By equipping with a frequency converter, the variable frequency speed regulation of the wire mesh belt shot blasting equipment can be achieved, thereby reaching the desired effect.

We offer a complete range of shot blasting machines with a bandwidth of 400-600-800-1000-1200-2000-2200-2500mm and others.The specific parameters are as follows:

NO.	Type Item		TDWD800	TDWD1000
1	Productivity	t/h	3	5
2	Abrasive flow	kg/min	4*240	6*240
3	Maximum weight of single piece	kg	20	20
4	Mesh belt width	mm	800	1000
5	Ventilation capacity	m3/h	9000	14000
6	Power	kw	～75	～105
