Product Description

The trolley type shot blasting machine is used to solve the shot blasting cleaning of large and medium-sized ductile iron and gray cast iron parts, removing sand, rust, oxide skin, dirt, etc. on the surface of the workpiece, making the surface of the workpiece appear metallic, eliminating internal stress, improving the fatigue resistance of the workpiece, increasing the adhesion of the paint film during painting, and ultimately achieving the goal of improving the surface and internal quality of the workpiece.
Trolley car type shot blasting machine has the characteristics of fully covering and cleaning complex circular workpieces with shot blasting, achieving the goal of complete cleaning. The perfect design of one end up and down workpieces greatly improves the work efficiency of the equipment, significantly improving the production efficiency of the factory. Different cleaning methods are used to select different numbers of shot blasters, scientifically reducing energy consumption. The bogie shot blasting machine replaces a batch of small specialized shot blasting equipment, saving manpower, material resources, energy consumption, and centralized dust treatment, greatly improving the environment of the casting workshop, truly achieving environmentally friendly and green production.

Technical parameters:

NO.	Type Item		TD765	TD7610	TD7620	TD7630	TD7640	TD7650
1	Cleaning size	mm	Ø2000*730	Ø2500*860	Ø2500*1100	Ø3700*980	Ø4000*1120	Ø4850*1280
2	Loading capacity	kg	5000	10000	20000	30000	40000	50000
3	Abrasive flow	kg/min	2*250	3*250	4*250	5*250	6*250	6*250
4	Total power	kw	～65	90	106	137	1178	192
